Thread Number: 44521  /  Tag: Member Selling Item(s)/Non Professionally
88 heritage II factory 13 nozzle and dump bag
[Down to Last]

Vacuumland's exclusive eBay Watch:
scroll >>> for more items
Post# 463134   5/14/2023 at 11:38 by 94kirbyg4 (owosso michigan)

94kirbyg4's profile picture
88 heritage 2 with factory original dump bag and 13 nozzle it has the special headlight hood and rear narrowed axle for the dump bag and the bottom sticker does indicate that it is a factory original 13 nozzle still even has factory lexan fan and cord
Hard to find combination
Im asking $150 buyer pays shipping


  Photos...       <              >      Photo 1 of 8         View Full Size
Post# 463239 , Reply# 1   5/20/2023 at 03:13 by Lesinutah (Utah)
Would

lesinutah's profile picture
Ya take 2 brand new crispy $20 bills. It's what I got mine for and it's a bagged system

Post# 463364 , Reply# 2   5/25/2023 at 19:46 by Centralvacs1928 (Chicagoland)

Tempting, it's in great shape and the small nozzle and dump out bag are such uncommon options.

This must have been the model for the "I love my 516 and I want a new one just like it!" buyer.


Post# 463372 , Reply# 3   5/26/2023 at 02:09 by Lesinutah (Utah)
It

lesinutah's profile picture
Didn't come with the shakeout bag it came with a type 2 fill time.
The bags been taken off and swapped out for the shakeout bag.


Post# 463375 , Reply# 4   5/26/2023 at 07:46 by myvacsrock (USA)
Les

Not a single Heritage 2 came factory new with a Style 2. The new bag type was one of features of the Heritage 2 launch.
My 13 Heritage 2 also came with a shake out bag. So it is entirely possibly that one did too.


Post# 463391 , Reply# 5   5/26/2023 at 21:38 by Lesinutah (Utah)
Diagram

lesinutah's profile picture
The heritage 2 legend had the option the heritage 2 legend 2 was the heritage that didn't have the option for the. Shakeout bag.
The diagrams are kirby manufactured exploded diagrams.
I was wrong nice catch.


  Photos...       <              >      Photo 1 of 2         View Full Size
Post# 464672 , Reply# 6   7/17/2023 at 23:02 by KirbyClassicIII (Milwaukie, Oregon)
LesinUtah

kirbyclassiciii's profile picture
Les,

The Heritage II originally came with the style 3 Mini Emtor bags and top adapter that would last all the way up to the G5. Other ways to tell if the shake out bag on this Heritage II Legend is original would be to see if it has the shorter 4.5" rear axle. Picture #2 shows it does have the right short axle.

Also, for the 13" nozzle, the headlight cap would be shaved down from the bottom in order to make it fit against the top of the '50s contours.

A few Legend IIs did have the shake-out bag as late as the fall of 1990... those ones are extremely rare and you can tell those ones apart from the 1989-90 batch by way of the maroon hammertoned Emtor instead of the black one, and also the maroon Renovation Group casting. This same batch also had the newer, G3-style tool kit.

The early version of the Legend II instruction book still made mention of the optional reusable cloth bag, but not the later one with the G3-style tool kit.

~Ben
